Webhook Setup Guide

Webhooks are the core of Atomik Trading's automation. They let external platforms like TradingView send trading signals directly to your connected broker accounts — executing trades in milliseconds without manual intervention.

How Webhooks Work

TradingView Alert → HTTP POST → Atomik Webhook URL → Match Strategy → Execute on Broker

1. You create a webhook in Atomik and get a unique URL + secret key
2. You paste that URL into TradingView (or any alert source)
3. When an alert fires, it sends a JSON payload to your webhook URL
4. Atomik validates the request, matches it to your activated strategy, and executes the trade on your linked broker account

Creating a Webhook

1. Log in to your Atomik Trading dashboard
2. Navigate to Webhooks in the sidebar
3. Click Create New Webhook
4. Configure settings:
   • Name: A descriptive label (e.g., "ES Long Entry")
   • Description: Optional notes about what this webhook does
5. Click Save — you'll receive:
   • A webhook token (the unique URL path)
   • A secret key (for request validation — save this immediately, it won't be shown again)

Your full webhook URL will be:

https://api.atomiktrading.io/api/v1/webhooks/{your-token}?secret={your-secret-key}

Webhook Payload Format

Atomik expects a JSON body with these fields:

Field	Type	Required	Description
action	string	Yes	"BUY" or "SELL" (case-insensitive)
comment	string	No	Exit signal type (see below)
quantity	number	No	Order size — only read by strategies set to From the alert JSON (see Where the quantity comes from)

Basic Examples

Open a long position:

{
  "action": "BUY"
}

Close a long position (full exit):

{
  "action": "SELL",
  "comment": "EXIT_FINAL"
}

Partial exit (50% of position):

{
  "action": "SELL",
  "comment": "EXIT_50"
}

Exit Comment Types

The comment field controls partial and full exits:

Comment	Effect
EXIT_50 or EXIT_HALF	Close 50% of position
EXIT_25	Close 25% of position
EXIT_75	Close 75% of position
EXIT_FINAL, EXIT_ALL, or EXIT_100	Close 100% of position
EXIT_33 (any number)	Close that percentage of position
ENTRY	New position entry
(no comment)	Defaults to full exit (100%)

Quantities are rounded up using math.ceil() to avoid leaving fractional shares.

Where the quantity comes from

Every strategy you activate chooses this for itself, in the activation dialog:

Set in Atomik (the default) — the quantity you typed when you activated the strategy is what trades, on every signal. A quantity in the alert is ignored. This is how webhooks have always worked, and nothing changes for you.

From the alert JSON — your alert sends "quantity" and that is what trades. Use this when the strategy itself decides position size. In TradingView, {{strategy.order.contracts}} gives the right number on both entries and exits:

{
  "action": "{{strategy.order.action}}",
  "comment": "{{strategy.order.comment}}",
  "quantity": "{{strategy.order.contracts}}"
}

Two things to know before switching a strategy over:

• Exits use it too. {"action": "SELL", "quantity": 1} closes 1 contract, not the whole position. If you leave quantity out of an exit, the comment percentages above still apply as normal.
• Max per signal. Set it when you switch, and any alert asking for more trades that cap instead. Leave it blank and a platform maximum of 50 contracts applies. This bounds a typo in your strategy — or anyone who gets hold of your webhook URL.

If an alert sends no quantity, or sends something unusable, the strategy falls back to the quantity configured in Atomik rather than skipping the trade.

The setting lives on each activated strategy, not on the webhook — so if you share a strategy, every subscriber still controls the size traded in their own account.

Payload quantities apply to single-account strategies only. Multi-account groups keep the per-account quantities you configured for them.

TradingView Integration

Setting Up Alerts

1. Open your chart in TradingView and add your indicator or strategy
2. Click the Alert button (bell icon) or press Alt+A
3. Set your condition (e.g., "RSI crosses below 30")
4. Under Notifications, check Webhook URL
5. Paste your full Atomik webhook URL (including ?secret=)
6. In the Message field, enter your payload:

For a simple buy alert:

{"action": "BUY"}

For a sell/exit alert:

{"action": "SELL", "comment": "EXIT_FINAL"}

Pine Script Strategy Example

If you're using a Pine Script strategy, you can use TradingView's built-in variables:

//@version=5
strategy("My Strategy", overlay=true)

// Your entry/exit logic
longCondition = ta.crossover(ta.sma(close, 20), ta.sma(close, 50))
shortCondition = ta.crossunder(ta.sma(close, 20), ta.sma(close, 50))

if longCondition
    strategy.entry("Long", strategy.long, comment="ENTRY")

if shortCondition
    strategy.close("Long", comment="EXIT_FINAL")

Then set the webhook message to:

{"action": "{{strategy.order.action}}", "comment": "{{strategy.order.comment}}"}

Webhook Security

Secret Key Validation

By default, webhooks require a valid secret key passed as a query parameter. Requests without a matching secret receive a 401 Unauthorized response.

IP Allowlisting

You can restrict which IP addresses can trigger your webhook:

1. Go to Webhooks → select your webhook → Edit
2. Enter allowed IPs as a comma-separated list (e.g., 52.89.214.238, 34.212.75.30)
3. Save — any request from a non-listed IP will receive 403 Forbidden

TradingView sends alerts from a known set of IP addresses listed in their documentation.

Rate Limiting

Webhooks are rate-limited to 10 requests per second to support high-frequency strategies while preventing abuse. Exceeding this limit returns 429 Too Many Requests.

Additionally, a 1-second idempotency window (Redis-backed) prevents duplicate executions from repeated signals.

Webhook Limits by Tier

Tier	Active Webhooks
Starter ($89/mo)	3
Pro ($129/mo)	10
Elite ($349/mo)	Unlimited

See Subscription & Pricing for full tier details.

Testing Your Webhook

1. Check the Webhook Logs: After triggering an alert, go to Webhooks → your webhook → Logs to see incoming requests, validation status, and any errors
2. Use a test alert: Create a TradingView alert with a condition that triggers immediately (e.g., "Price crosses above $0.01") to verify the connection without waiting for a real signal
3. Paper trade first: Connect a paper/demo broker account and test with real alerts before going live

Troubleshooting

Problem	Solution
Alert fires but no trade executes	Check webhook logs for errors. Verify the secret key is correct in the URL. Confirm the webhook is linked to an activated strategy with an active broker account.
401 Unauthorized	Secret key is missing or incorrect. Re-copy from webhook settings.
403 Forbidden	IP not in allowlist, or your subscription is inactive. Check both.
429 Too Many Requests	You're exceeding 10 requests/second. Reduce alert frequency.
404 Not Found	Webhook token is wrong or webhook has been deleted. Verify the URL.
Duplicate trades	The 1-second idempotency window should prevent this. If duplicates persist, check that your alert isn't firing multiple times per bar (use "Once Per Bar Close").

Response Format

Successful webhook requests return 202 Accepted:

{
  "status": "accepted",
  "message": "Webhook received and being processed",
  "webhook_id": 123,
  "timestamp": "2026-03-20T12:34:56.789123"
}

The trade is processed asynchronously — check your dashboard or broker account for fill confirmation.
